V-i30
Veterinary Blood Gas Analyzer
Contact
Add to List
product description
Features
Including 34 parameters in one test
34 parameters of blood gases,electrolytes and metabolites
10 measured parameters:K+,Na+,Cl-,iCa2+,PH ,pCO2,pO2,Glu ,Lac ,Hct
24 calculated parameters:cH+(T),pH(T),pCO2(T),pO2(T),pO2(A-a)(T), pO2(a/A)(T) ,
RI(T),pO2(T)/FiO2,cH+,iCa2+(7.4),HCO3-act,HCO3-std,BE(ecf),BE(B),BB(B),AG,sO2(est),tHb(est),TCO2,pO2(A-a),pO2(a/A),RI,mOsm,pO2/FiO2
Parameters
|
Parameter |
Range |
Unit |
|
K+ |
2.0-9.0 |
mmol/L |
|
Na+ |
100-180 |
mmol/L |
|
Cl – |
65-140 |
mmol/L |
|
iCa2+ |
0.25-2.50 |
mmol/L |
|
pH |
6.50-8.00 |
– |
|
pCO2 |
10.0-150.0 |
mmol/L |
|
pO2 |
10-700 |
mmol/L |
|
Glu |
1.1-38.0 |
mmol/L |
|
Lac |
0.50-20.00 |
mmol/L |
|
Hct |
10%-70% |
– |
Specifications
|
Parameter |
Specifications |
|
Sample |
whole blood |
|
Technology |
electrochemical biosensor technology |
|
Sample volume |
150µLO |
|
Size |
235mm x210mm x160 mm |
|
Weight |
3±0.5kg |
|
Test time |
5 min |
|
Memory |
99999 results |
|
Operating condition |
18°C~30°CO |
