VME-5E
Vet Slit Lamp
Contact
Add to List
product description
Description
Universal Slit lamp with 3 steps magnification;
Converging Optical Path;
The optical lenses are made of glass imported from Germany: multi-coated, mildewproof and anti-reflection, given a superior clarity image of observers;
The adaptor for Applanation Tonometer are universal.
Technical Specifications
|
PARAMETER |
SPECIFICATION |
|
Microscope Type |
Converging Stereoscope |
|
Magnification |
Three-step magnifications |
|
Eye piece |
10x |
|
Magnification |
10x , 16x , 25x |
|
Adjustable Range of PD (mm) |
55~75 |
|
Adjustable Diopter |
-8D~+8D |
|
Slit Width(mm) |
0-9 adjustable |
|
Slit Height(mm) |
1-9 adjustable |
|
Slit Angle |
0-180° |
|
Slit Inclination |
5°, 10°, 15°, 20°，4 steps for choose |
|
Aperture Diameter (mm) |
Φ9, Φ8, Φ5, Φ3, Φ2, Φ0.2 |
|
Filters |
Heat Absorption, Grey, Red Free, Cobalt Blue |
|
Illumination Bulb |
12V / 30W or 12V/50W halogen bulb |
|
Fixed Lamp |
Red LED |
|
Voltage/frequency |
AC220V, 50Hz or AC110V, 60Hz |
|
Power |
60VA |
|
Optional: Applanation Tonometer, Elevating table |
|
