VED-3112C

Portable Nasopharyngoscope/ Bronchoscope

product description

Features

  • The multifunctional intubation portable flexible endoscope using polycarbonate new composite handle, reasonable designed the clamp hole position, the washable pipe system can protect the lotion unobstructed, to prevent the pipeline blockage. When do surgery , the suction valve is convenient, removable, safe and reliable, so that users do not feel fatigue in the operation.
  • The excellent operation of the traction device an be easily transfer and adjust the bending parts to upward, downward. Can smoothly and fastly reach to the desired site of observation. And timely and accurate detection of diseased tissue.
  • The multi-function portable flexible endoscope with 3.5 inch high-resolution display, with a key camera video image brightness electronic zoom, mediation, easy removal and disassembly for cleaning and disinfection.
  • The scope with multi-coated high transmittance imaging system, round field of view, wide viewing angle, wide field of view, the scene is broad and wide, 3-50 mm range can see more clear picture, so that the observation and diagnosis correctness greatly improved.
  • The high-definition CMOS camera makes users to get clearer, wider and brighter image.



Technical Specifications

PARAMETER

VED-3112C1

VED-3112C2

View of field

120°

120°

Diameter of distal-end

Φ3.0mm

Φ3.8mm

Outer diameter of insert tube

Φ2.8mm

Φ3.6mm

Depth of view

3-50mm

3-50mm

Bending range

Up: 270°

Down: 160°

Up: 180°

Down: 130°

Clamp aperture

Φ1.0mm

Φ1mm

Working length

600mm

600 mm

LCD

3.5”

3.5”



Parts List

PRODUCT NAME

UNIT

QUANTITY

Portable scope

set

1

Leak detector

set

1

Biopsy forceps

pc

2

Cleaning brush

pc

2

Attract valve anti jet cover

set

2

Endoscope case

set

1

3.5’’ LCD

set

1

Charger

set

1

Video Output line

pc

1

Certificate

pc

1

User manual

pc

1

Light guiding line

pc

1
