VED-400A
Video Gastroscope/ Colonoscope
Contact
Add to List
product description
Specifications of Endoscope
|
PARAMETER |
SPECIFICATION |
|
Top diameter |
≤Φ14.0mm |
|
Input tube |
≤Φ14.0mm |
|
Biopsy channel |
≥Φ6.0mm |
|
Working length |
≥5000mm |
|
Total length |
≥5300mm |
|
Field of view |
≥140º |
|
Depth of field |
≥3-100mm |
|
Image solution |
≥480,000 pixels (CCD) |
|
Bending angles |
Up ≥180º, down ≥90º, L/R ≥100º, maximum 230 |
|
Image frozen |
16 images frozen, store, playback. |
Specifications of Processer & Light Source
|
PAREMETER |
SPECIFICATION |
|
Contrast adjustment |
0-128 |
|
Image adjustment |
Color adjustment level: 0-128, vessel enhancement |
|
Metering mode |
AVE/PEAK |
|
Image enhance |
0-30 |
|
White balance |
Auto/manual white balance |
|
Pump |
pressure 30-80Mpk, air supply 4L/min-10L/min |
|
Illuminance |
≥200,000Lx, LED light source 30,000hours life |
|
SD record card |
16G SD record card |
Specifications of Suction Device
|
PAREMETER |
SPECIFICATION |
|
Vessel capacity |
Not less than 1L |
|
Maximum suction volume |
20L / Min |
Parts List
|
PRODUCT NAME |
QUANTITY |
|
EMV-400D video Endoscope |
1 |
|
Biopsy forceps |
2 |
|
Cleaning brush |
1 |
|
Mouth pad |
3 |
|
Leak detector |
1 |
|
Leak cover |
1 |
|
Clean lid |
1 |
|
Attract the valve body baffle cap |
2 |
|
Water bottle interface seal ring |
6 |
|
Wash ear ball |
1 |
|
Water injection bottle assembly |
1 |
|
Endoscopic box |
1 |
|
Instructions |
1 |
|
EMV-3000 Endoscope processor &light source (With air pump and SD record card and Rigid endoscope interface) |
|
|
EMV-3000 Endoscope processor &light source (LED lamp) |
1 |
|
power cable |
1 |
|
Instructions |
1 |
|
Suction device |
|
|
Suction device |
1 |
|
power cable |
1 |
|
Instructions |
1 |
|
Trolley |
1 |
|
19” LCD monitor |
|
