VED-800
Portable USB Video Gastroscope/ Colonoscope
Contact
Add to List
product description
Features
- Bending operation: Traction chain structure, whole sealed waterproof
- Image display: Two image display optional
- Split machine: Main part and light source are splited
- Quality certification: ISO
- Warranty: One year(free), permanent repairs (not free)
- Package size: 64*18*48cm (G.W.:5.18kgs)
Technical Specifications
|
PARAMETER |
SPECIFICATION |
|
Diameter of distal-end |
Φ8.0mm |
|
Diameter of insert tube |
Φ8.0mm |
|
Clamp aperture |
Φ2.2mm |
|
Working length |
1500mm |
|
Total length |
1800mm |
|
View of field |
140° |
|
Depth of view |
3-100mm |
|
Resolution |
CMOS 1,000,000 pixels |
|
Tip deflection |
Up 180°, Down 90°, L/R 100° |
Package list
|
PRODUCT NAME |
UNIT |
QUANTITY |
|
Portable scope |
set |
1 |
|
Leak detector |
set |
1 |
|
Biopsy forceps |
pc |
2 |
|
Cleaning brush |
pc |
2 |
|
Attract valve anti jet cover |
set |
2 |
|
Endoscope case |
set |
1 |
|
USB line |
set |
1 |
|
User manual |
pc |
1 |
|
Certificate |
pc |
1 |
Optional
|
PRODUCT NAME |
PICTURE |
SPECIFICATIONS |
|
Laptop computer |
HUAWEI MateBook D 14 SE |
|
|
Light cold source machine |
1. Voltage: 220V-240V 2. Frequency: 50-60HZ 3.lamp Power: 15V-150W environmentally friendly halogen tungsten lamp 4. Illumination: 70000LX (using special measuring tools) 5. Color Temperature: 3000~7000K 6. Air Pump Pressure: 30-60kpa 7. Air Flow: 4L/min-10L/min (Quiet pump) |
|
|
Trolley |
|
