VDL26
Diode Laser Surgery Machine
Product Categories
-
Animal Monitoring & Life Support
-
Operating Theatre Equipment
-
Animal Diagnostic Laboratory
- Automatic Integrated Gene Detection System
- Hematology Analyzer
- Elisa Reader
- Chemistry Analyzer
- Blood Gas Electrolyte Analyzer
- Urine Analyzer
- Blood Gas&Immunoflurescence Analyzer
- Biological Safety Cabinet
- Biological Microscope
- Centrifuge
- Medical Pharmacy Refrigerator
- Blood Bank Refrigerator
- Combined Medical Refrigerator and Freezer
- Medical Freezer
- Laboratory Incubator
- Dry Oven
- Pet Rapid Test
-
Sterilizer (Autoclave)
-
Medical Imaging
-
Clinical Examination
-
Dental Equipment
-
Pet Grooming
Contact
Add to List
product description
Features
- New friendly used protocol
- Big color touch screen
- Quick connector battery box
- Highly integrated and modular design
- Compact & lightweight, easy to transport
- Output power calibration at the end of fibers
- Preprogrammed and customizable parameters
- New design inside to make maintenance easy and low cost
- Scope of application: Dentistry, Lipolysis (Laser fat burning), EVLT (Endovenous laser treatment), Spider Vein, ENT, Dermatology, Orthopedics, PLDD (Percutaneous Laser Dsic Decompression), Neuro surgery, Gynaecology, General surgery, Therapy, Veterinary.
Technical Specifications
|
PARAMETER |
SPECIFICATION |
|
Wavelength |
650nm, 810nm, 980nm, 1064nm |
|
Maximum Power |
CW 30.5 W, ISP 75.5 W |
|
Operation Mode |
CW, Single or Repeat Pulse |
|
Pulse Duration |
25μs-900ms |
|
Repetition Rate |
1Hz-20KHz |
|
Transmission system |
Contact: fibers of 400μm, 600μm and 1000μm with SMA905 connector; Non-contact: fibers, tips and hanpiece |
|
Aiming Beam |
Red Diode Laser of 650nm, 5mW (max), adjustable brightness |
|
Cooling |
Air cooling |
|
Control Mode |
Color LCD touch Screen |
|
Laser Class |
4 |
|
Fuse |
F5AH250VP |
|
Power supply |
100-240V, 50-60Hz, 350VA |
|
Safety classification |
Class I Type B |
|
Dimension |
250*130*240mm, 5.6kg |
|
Operating Temperature |
+5 ~ +40 ℃ |
|
Storage / Transport Temperature |
-20 ~ +50 ℃ |
|
Humidity |
Storage / Transport: 10% – 80%, Operating: 30% – 60% |
|
Waterproof level |
IPX1 |
|
Footswitch Waterproof level |
IPX8 |
